VTOL & Hybrid UAVs · UAV Tech lineage
KSHATRA M-12
Compact hybrid VTOL for extended-endurance surveillance
Image Gallery
Technical Overview
The KSHATRA M-12 is a compact hybrid-electric VTOL platform combining one forward motor with four vertical motors. Precise vertical take-offs from confined spaces, long-range coverage and stable hovering make it well suited to surveillance missions requiring detailed data capture with lightweight sensors.
Specifications
| Wingspan / Length / Height | 2.6 m / 1.6 m / 0.4 m |
|---|---|
| Propulsion | 1 forward + 4 vertical electric motors |
| Empty / Gross weight | 7 kg / 12 kg |
| Max payload | 2 kg |
| Cruise / Max speed | 22 m/s / 30 m/s |
| Max range | 60 km |
| Endurance | 125 minutes |
| Note | Specifications subject to change without notice — source: authorized-partner datasheet. |
Mission Applications
- ▸Surveillance
- ▸Long-Endurance Monitoring
