KSHATRA Data Acquisition Unit
High-speed on-board image-processing acquisition system
Image Gallery
Technical Overview
This Data Acquisition Unit is built around a Zynq UltraScale+ MPSoC ARM processor SBC with 16 GB DDR-4 memory, supporting MIL-STD-1553B, gigabit Ethernet and a PCIe 2.0 interface. Two high-speed ADC channels sample at up to 310 MSPS alongside two low-speed channels at 40 MSPS, with 16 digital inputs and 16 digital outputs for on-board image-processing workloads.
Specifications
| Processor | Zynq UltraScale+ MPSoC (ARM) SBC |
|---|---|
| Memory | 16 GB DDR-4 |
| ADC channels | 2× high-speed @ 310 MSPS, 2× low-speed @ 40 MSPS |
| Digital I/O | 16 inputs, 16 outputs |
| Interfaces | MIL-STD-1553B, Gigabit Ethernet, PCIe 2.0 |
| Note | Specifications subject to change without notice — source: authorized-partner datasheet. |
Mission Applications
- ▸On-Board Image Processing
- ▸Sensor Data Acquisition
