KSHATRA MS10 Cloud Lidar
Motorised cloud-height lidar for meteorological and airfield use
Image Gallery
Technical Overview
The KSHATRA MS10 Cloud Lidar transmits a 1064 nm laser and receives the reflected signal through a Cassegrain telescope and beam concentrator onto an avalanche photodiode, digitizing at 40 MSPS on a high-speed UltraScale FPGA. A motorized gimbal points the system across the full azimuth and from -20° to +90° elevation, in a temperature-controlled, IP66-rated enclosure with Ethernet/WiFi connectivity to a LabVIEW-based host GUI.
Specifications
| Detection range | Cloud height up to 10 km |
|---|---|
| Height resolution | 5 meters |
| Scan modes | Fixed, circular, vertical & conical |
| Laser | 1064 nm, Cassegrain telescope receiver |
| Data acquisition | 40 MSPS, UltraScale FPGA |
| Gimbal | Azimuth 0–360°, elevation -20° to +90° |
| Enclosure | IP66, temperature-controlled |
| Connectivity | Ethernet & WiFi, LabVIEW host GUI |
| Note | Specifications subject to change without notice — source: authorized-partner datasheet. |
Mission Applications
- ▸Meteorology
- ▸Airfield Operations
- ▸Atmospheric Research
