Fixed-Wing UAVs · UAV Tech lineage — M165 Series
KSHATRA M165 STOL
Heavy-lift, short-runway UAV for high-volume logistics
Image Gallery
Technical Overview
The KSHATRA M165 STOL is a modular variant of the M165 VTOL that operates from less than 50 m of take-off runway distance while adding roughly 50% more cargo and range capability. It is designed to give logistics operators better profit margins through higher cargo volumes at cost-effective freight rates.
Specifications
| Wingspan / Length / Height | 4.5 m / 3.4 m / 1.1 m |
|---|---|
| Forward propulsion | 29 hp IC engine |
| Indigenous content | 62% |
| Empty / Gross weight | 75 kg / 150 kg |
| Max payload | 60 kg |
| Max fuel capacity | 45 L |
| Cruise / Max speed | 100 km/h / 135 km/h |
| Max range | 600 km |
| Take-off distance | < 50 m |
| Note | Specifications subject to change without notice — source: authorized-partner datasheet. |
Mission Applications
- ▸Defense Logistics
- ▸Long-Haul Cargo
